MAC Quantum Wash

SRP from £5,115.00 + VAT

The MAC Quantum Wash features tight beams, beautiful wash fields, a market-leading colour palette, and uniform mixing that combines to accommodate the most demanding applications, offering brightness and perfection.

Combining an impressive 750 watt of RGBW LED power with Martin’s market leading optical system ensures that the 1:5 zoom on the MAC Quantum Wash operates with maximum output and superior performance.

  • RGBW LED colour mixing with unique and expressive Colorganics™ system for superior default white and deep saturated colours
  • 1:5 zoom for tight beams and even washes
  • Beam twister effects: Rotating front lens for stunning mid-air and projection effects
  • Bright and perfect RGBW LED wash light for demanding applications
  • Quick 1:5 zoom for tight beams and even washes
  • Unique and expressive Colorganics™ system
  • Highly efficient optical system
  • Eye-candy Aura Effect™
  • Beamtwister effects via rotating front lens
  • Very low weight and compact design
  • Super high-speed movements and effects
Length452 mm (17.8 in.)
Width (across yoke)431 mm (17 in.)
Height (maximum)581 mm (22.9 in.)
Height (head straight up)511 mm (20.1 in.)
Weight21 kg (46.3 lbs.)
Dynamic Effects
Colour mixingRGBW
Beam effectsBeam twister, light and colour morphing, colour spin
'Colour wheel' effect36 solid colours plus white, variable-speed 'colour wheel rotation' effect and random colour
Colour ring effects36 split ring colours with variable-speed colour wheel rotation effects
Shutter effectElectronic, with variable speed regular and random strobe
Pre-programmed effectsRange of synchronized and independent colour, intensity, beam twister and zone effects
Electronic dimmingFour dimming curve options
Colour temperature controlVariable 2000 - 10 000 K
Pan and tilt speedAdjustable via onboard control panel and DMX
Control and Programming
Control systemDMX
Control optionsIndependent control of colour ring/beam zones
Macro programs selectable via DMXRange of synchronized and independent colour, intensity, beam twister and zone effects
Control resolution8-bit, with 16-bit control of pan, tilt, dimming and lens rotation
DMX channels33/17
Setting and addressingControl panel with backlit graphic display
DMX complianceUSITT DMX512-A
RDM complianceANSI/ESTA E1.20
Fixture software updateUSB memory device or USB/DMX hardware interface over DMX link
Light source50 x 15 W RGBW LEDs
LED refresh rateBeam 3000 Hz, Aura 3000 Hz
Minimum LED lifetime50 000 hours (to >70% luminous output)*
Zoom range11–53° (1:5)
Output16 000 lm
*Figure obtained under manufacturer´s test conditions
HousingHigh-impact flame-retardant thermoplastic
Protection ratingIP20
Mounting points2 pairs of 1/4-turn locks
LocationIndoor use only, must be fastened to surface or structure
Minimum distance to combustible materials0.2 m
Minimum distance to illuminated surfaces2.0 m
AC power inputNeutrik PowerCon
DMX and RDM data in/out5-pin locking XLR
AC power120-240 V nominal, 50/60 Hz
Maximum total power consumption1020 W
Power supply unitAuto-ranging electronic switch mode
Typical power consumption, all effects static, zero light outputApprox. 50 W
Typical half-cycle RMS inrush current10.3 A
Typical Power and Current
120 V, 60 Hz7.4 A, 880 W, PF 0.999
208 V, 60 Hz4.2 A, 860 W, PF 0.995
230 V, 50 Hz3.8 A, 856 W, PF 0.993
240 V, 50 Hz3.7 A, 858 W, PF 0.992
Measurements made at nominal voltage with all LEDs at full intensity. Allow for a deviation of +/- 15%.
CoolingForced air (temperature-regulated, low noise, user-definable levels)
Maximum ambient temperature (Ta max.)40° C
Minimum ambient temperature (Ta min.)5° C
Max. total heat dissipation (calculated, +/- 15%)3480 BTU/hr.
EU safetyEN 60598-2-17 (EN 60598-1), EN 62471
EU EMCEN 55015, EN 55032, EN 55103-2, EN 61000-3-2, EN 61000-3-3, EN 61547 US safety
US EMCFCC Part 15 Class A
Canadian safetyCSA C22.2 No. E598-2-17 (CSA E60598-1)
Canadian EMCICES-003 Class A
Australia/NZC-TICK N4241
SKU Image Name Colour/description
MAR1239 MAC Quantum Wash MAC Quantum Wash
MAR1241 MAC Quantum Wash in 2-unit flightcase MAC Quantum Wash in 2-unit flightcase
MAR1240 MAC Quantum Wash - White MAC Quantum Wash - White
