MAC Quantum Profile
This extremely bright LED profile fixture combines top-quality white light with a fast, smooth CMY colour mixing system and crisp gobo projection on surfaces as well as mid-air.
With all this and the new Animotion™ FX system that allows never-before seen beam animations, the market is now finally seeing the first real 700/800 W discharge lamp replacement in a profile fixture that effectively harnesses cutting-edge LED technology.
- First real alternative to a 700/800 watt HID fixture
- Flat field, crisp image, high contrast
- Full feature set including CMY colour mixing and 1:3 zoom
- First real alternative to a 700/800 watt HID fixture
- Flat field, crisp image, high contrast
- Full feature set including CMY colour mixing and 1:3 zoom
- Very low weight and compact design
- Super high-speed movements and effects
- Consistent photometric performance via latest LED technology
| Physical | |
|---|---|
| Length | 452 mm (17.8 in.) |
| Width (across yoke) | 431 mm (17.0 in.) |
| Height (head straight up) | 642 mm (25.3 in.) |
| Height (maximum) | 648 mm (25.5 in.) |
| Weight | 23.2 kg (51.1 lbs.) |
| Dynamic Effects | |
| Colour mixing | CMY, independently variable 0 - 100% |
| Colour wheel | 6 colour filters plus open |
| Rotating gobo wheel | 6 interchangeable gobos plus open, wheel rotation, gobo rotation, indexing and shake |
| Static gobo wheel | 10 gobos plus open, wheel indexing, rotation and shake |
| Beam effects | Rotating three-facet prism |
| Zoom | Motorised |
| Focus | Motorised, with zoom-focus tracking |
| Iris | 0 - 100%, pulse effects |
| Shutter effect | Electronic, with variable speed regular and random strobe |
| Electronic dimming | Four dimming curve options Pan: 540° |
| Tilt | 268° |
| Pan and tilt speed | Adjustable via onboard control panel and DMX |
| Control and Programming | |
| Control system | DMX |
| RDM | Implemented |
| Control resolution | 8-bit, with 16-bit control of dimming, gobo indexing, zoom, focus, pan and tilt |
| DMX channels | 19/27 |
| Setting and addressing | Control panel with backlit graphic display |
| DMX compliance | USITT DMX512-A |
| RDM compliance | ANSI/ESTA E1.20 |
| Transceiver | RS-485 |
| Fixture software update | Direct using USB memory stick or via DMX link using Martin USB Duo™ DMX Interface Box |
| Optics | |
| Light source | 475 W LED engine |
| LED refresh rate | 3000 Hz |
| Minimum LED lifetime | 50 000 hours (to >70% luminous output)* |
| Zoom range | 12° - 36° (1:3) |
| Output | 12 700 lumens |
| *Figure obtained under manufacturer´s test conditions | |
| Construction | |
| Colour | Black |
| Housing | High-impact flame-retardant thermoplastic |
| Protection rating | IP20 |
| Installation | |
| Mounting points | 4 pairs of quarter-turn locks |
| Location | Indoor use only, must be fastened to surface or structure |
| Orientation | Any |
| Minimum distance to combustible materials | 0.2 m |
| Minimum distance to illuminated surfaces | 2.0 m |
| Connections | |
| AC power input | Neutrik PowerCon |
| DMX and RDM data in/out | 5-pin locking XLR |
| Electrical | |
| AC power | 120-240 V nominal, 50/60 Hz |
| Power supply unit | Auto-ranging electronic switch mode |
| Maximum total power consumption | 750 W |
| Typical power consumption, all effects static, zero light output | Approx. 50 W |
| Typical half-cycle RMS inrush current | 10.3 A |
| Typical Power and Current | |
| 120 V, 60 Hz | 4.8 A, 576 W, PF 0.999 |
| 208 V, 60 Hz | 2.8 A, 568 W, PF 0.991 |
| 230 V, 50 Hz | 2.5 A, 565 W, PF 0.988 |
| 240 V, 50 Hz | 2.4 A, 565 W, PF 0.988 |
| Measurements made at nominal voltage with all LEDs at full intensity. Allow for a deviation of +/- 10%. | |
| Thermal | |
| Cooling | Forced air (temperature-regulated, low noise, user-definable levels) |
| Maximum ambient temperature (Ta max.) | 40° C |
| Minimum ambient temperature (Ta min.) | 5° C |
| Total heat dissipation (calculated, +/- 10%) | 2000 BTU/hr. |
| Approvals | |
| EU safety | EN 60598-2-17 (EN 60598-1), EN 62471 |
| EU EMC | EN 55015, EN 55032, EN 55103-2, EN 61000-3-2, EN 61000-3-3, EN 61547 US safety |
| US EMC | FCC Part 15 Class A |
| Canadian safety | CSA C22.2 No. E598-2-17 (CSA E60598-1) |
| Canadian EMC | ICES-003 Class A |
| Australia/NZ | C-TICK N4241 |
| SKU | Manufacturer’s SKU | Image | Name | Colour/description |
|---|---|---|---|---|
| MAR1236 | 90240000HU | | MAC Quantum Profile in cardboard | |
| MAR1238 | 90240010HU | | MAC Quantum Profile in 2-unit flightcase | |
| MAR1237 | 90240005HU | | MAC Quantum Profile White in cardboard |
