Martin MAC Encore Performance CLD

Overview

MAC Encore™ Performance CLD integrates cutting-edge LED technology with a proprietary and innovative light engine carefully engineered to generate pristine, full spectrum light with ultra-high colour rendition.

The feature-packed moving head offers unparalleled 6000 K crisp, neutral daylight. Its advanced colour mixing system delivers the full palette from smooth and subtle pastels to rich and vibrant saturated colours. Moreover, it offers a fully variable colour correction to tungsten/orange.

Unparalleled 6000 K cold white light quality
Super silent cooling and effects operation
Best-in-class size/weight/performance ratio

Key Features

Pure white LED engine with 6000 K CCT
A flat field without colour temperature variation during zoom and dimming.
Flicker-free operation—LED driver frequency suitable for all camera applications.
Ultra-low noise—Combines convection and forced air cooling with user-selectable output vs. sound level control.
Fully electronic dimmer/shutter control with various dimming curves and tungsten red-shift emulation.
Vibrant CMY colour mixing with a superior palette of colours ranging from light and smooth pastel shades to rich, saturated primaries.
Variable CTO—daylight to tungsten CCT control and expansion of the CMY palette that stays true to the black body curve.
Colour wheel—6 interchangeable dichroic filters + open.
1:4 zoom—precise and fast, silent zoom with auto- linked focus.
Four framing shutter blades with individual +/- 30° adjustment and entire system rotation of +/- 55° allow for high-precision cue repeats.
Five rotating glass gobos with next to zero focal separation from the framing system.
Animation wheel with continuous multi-directional rotation and indexing with variable angle, speed and direction.
Animotion™ FX System—internal dimming effect macros for stunning 3D mid-air and projection effects.
Precise and tight iris with adjustable dynamic effects.
Soft frost—a light frost that leaves gobo artwork and framed images visible with a beautiful soft edge.
Heavy frost available as an optional accessory.
Super precise and silent pan/tilt movement and positioning due to 3-phase stepper motor technology and absolute position monitoring.
Compact size—L: 452 mm x W: 480 mm x H: 733 mm (L: 17.8 in x W: 18.9 in x H: 28.9 in).
Low weight—31 kg/68 lbs.
Foam rubber (SiP) flightcase insert for secure shipment.

Specifications

Physical
Length	452 mm (17.8 in.)
Width (across yoke)	480 mm (18.9 in.)
Height (maximum)	740 mm (29.2 in.)
Height (head straight up)	731 mm (28.8 in.)
Weight	31 kg (68.4 lbs.)
Minimum center-to-center distance in side-by-side installation	700 mm (27.6 in.)
Dynamic Effects
Colour mixing	CMY, independently variable 0 - 100%
Colour temperature control	Variable 6000 - 2700 K
Colour wheel	6 x interchangeable dichroic filters + open, indexing, continuous rotation, random colour
Rotating gobo wheel	5 x interchangeable texture/breakup gobos + open, indexing, continuous rotation and shake
Gobo animation	Interchangeable animation wheel, indexing, continuous rotation with variable speed and direction
Framing	Rotatable framing module, +/- 55°, 4 x individually controllable blades with variable angle and position
Iris	Variable 0 - 100%
Frost	Variable 0 - 100%
Dimmer/shutter	0 - 100% continuous dimming, regular and random strobe and pulse effects, instant open and blackout
Dimming options	Choice of four dimming curves
Pre-programmed effects	Two ranges of FX, independent or synchronized/combined Focus
Pan	540°
Tilt	268°
Position correction system	Absolute position monitoring
Control and Programming
DMX channels	38
Setting and addressing	Control panel with backlit graphic display and jog wheel or via DMX 16-bit control
Movement control options	Tracking and vector
Fixture identification	User-settable ID number
DMX compliance	USITT DMX512-A
RDM compliance	ANSI/ESTA E1.20
Transceiver	Opto-isolated RS-485
Fixture software update	USB memory device or over DMX link
Optics
Light source	6000 K white LEDs
Total LED engine power	468 W
Minimum LED lifetime	50 000 hours (to >80% luminous output)*
Zoom range	12° - 48° one-tenth peak (1:4)
*Figure obtained under manufacturer's test conditions
Photometric Data
Light engine luminous output	≥ 39 400 lumens
Fixture luminous output	11 600 lumens
CRI (Color Rendering Index)	>80
CQS (Color Quality Scale)	>80
TM-30 Rf (IES TM-30-15 Fidelity Index)	>80
TM-30 Rg (IES TM-30-15 Gamut Index)	>95
TLCI (Television Lighting Consistency Index)	>70
Construction
Colour	Black
Housing	High-impact flame-retardant thermoplastic
Protection rating	IP20
Installation
Mounting points	4 pairs of 1/4-turn locks
Location	Dry location only, must be fastened to surface or structure
Orientation	Any
Minimum distance to combustible materials	0.2 m (8 in.)
Minimum distance to illuminated surfaces	2.0 m (6.6 ft.)
Connections
AC power input	Neutrik TRUE1 socket (accepts Neutrik TRUE1 NAC3FX-W connector) DMX and RDM data in/out: 5-pin locking XLR
Electrical
AC power	120-240 V nominal, 50/60 Hz
Power supply unit	Auto-ranging electronic switch-mode
Power consumption, all effects static, zero light output	64 W Half-cycle RMS inrush current at 230 V, 50 Hz: 10.3 A
Typical Power and Current
120 V, 60 Hz	5.0 A, 596 W, PF 0.998
208 V, 60 Hz	2.9 A, 581 W, PF 0.988
230 V, 50 Hz	2.6 A, 580 W, PF 0.981
240 V, 50 Hz	2.2 A, 585 W, PF 0.979
Figures are typical, not maximum. Measurements made at nominal voltage with all LEDs at full intensity. Allow for a deviation of +/- 10%. PF = power factor
Thermal
Cooling	Combined convection and forced air (temperature-regulated, low noise, user-definable levels)
Maximum surface temperature, steady state, Ta=40° C	75° C (167° F)
Maximum ambient temperature (Ta max.)	40° C (104° F)
Minimum ambient temperature (Ta min.)	5° C (41° F)
Total heat dissipation (calculated, +/- 10%)	2000 BTU/hr.
Approvals
EU safety	EN 60598-2-17, EN 62471, EN62493
EU EMC	EN 55015, EN 55032, EN 55103-2, EN 61000-3-2, EN 61000-3-3, EN 61547 US safety
US EMC	FCC Part 15 Class A
Canadian safety	CSA C22.2 No. E598-2-17
Canadian EMC	ICES-003 Class A
Australia/NZ	RCM

Downloads

Spec Sheet

Audio/Video

Watch

Product Variants

SKU	Manufacturer’s SKU	Name	Colour/description
MAR1229	90234005HU	MAC ENCORE PERFORMANCE,CLD,SIP	in cardboard box with SIP foam flightcase insert
MAR1228	90234000HU	MAC ENCORE PERFORMANCE,CLD,EPS	in cardboard box with polystyrene packaging
MAR1791	90234010HU	MAC ENCORE PERFORMANCE,CLD,EPS,WHITE	90234010HU
