ERA 800 Profile
800 W LED Moving Head Profile With CMY Colour Mixing
_original-w118h88.jpg)
_original.jpg)
A Truly Versatile LED Profile
Combining a fully-featured, cost-efficient and no-nonsense fixture, the Martin ERA 800 Profile is perfect for stadium-sized entertainment and rental productions. Designed to fulfill the demand for a tour-worthy, compact, LED profile moving head with enhanced gobo load-out aimed for the largest stages, the ERA 800 Profile bundles an extremely efficient 800 W, 6,500 K LED engine that produces a powerful 34,000 lumens and delivers sharp image projection with a flat field. Additional benefits include 1:8 zoom, electronic dimming and strobe, CMY/CTO, iris for beam adjustment and dual rotating gobo wheels plus an additional static wheel. It’s also loaded with user-favorite gobos from the renowned Martin MAC range that include a wide variety of effects, especially when combined with the included rotating prisms.
In addition to the largest concert and touring productions, the ERA 800 Profile is ideal for cruise lines, houses of worship, live TV productions, and corporate shows that require a truly versatile LED profile that offers near limitless design and usage potential.
- Bright 800 W / 6,500 K LED light source
- 34,000 lumen output
- Crisp optics with flat field
- 1:8 fast zoom
- Fat beam look with 160 mm front lens
- CMY color mixing - vibrant color mixing with a superior palette of colors matching the MAC range
- Linear CTO - daylight to tungsten CCT control and expansion of the CMY palette
- 6-slot color wheel - for added color choice and split color effects
- 12 rotating/indexing gobos - all renowned Martin glass gobos
- 7 static gobos for great morphing effects
- Animation wheel with continuous bi-directional rotation
- Iris – fast and tight iris
- Two prisms - 4-facet and linear - rotation and index control for dynamic effects
- Soft frost - a light frost leaves gobo artwork visible with a beautiful, soft edge
- Heavy frost - for wash light effects
- Compact and low weight design
| PHYSICAL | |
|---|---|
| Weight | 40.0 kg (88.2 lbs.) |
| Minimum center-to-center distance in side-by-side installation | 730 mm (28.8 in.) |
| Length (head) | 608 mm (24.0 in.) |
| Length (base) | 416 mm (16.4 in.) |
| Width (base) | 290 mm (11.4in.) |
| Width (across yoke) | 431 mm (17in.) |
| Height (head straight up) | 802 mm (31.6 in.) |
| Height (maximum) | 851 mm (33.5in) |
| DYNAMIC EFFECTS | |
| Electronic shutter effect | Strobe effect, pulse effects, instant open and blackout |
| Electronic dimming | 0 - 100%, four dimming curve options |
| Color mixing | CMY, independently variable 0-100% |
| Color wheel | 6 color filters plus open |
| Gobo animation | Animation wheel, indexing, continuous rotation with variable speed and direction |
| Rotating gobo wheel | 6 gobos plus open, wheel rotation, gobo rotation, indexing and shake |
| Second rotating gobo wheel | 6 gobos plus open, wheel rotation, gobo rotation, indexing and shake |
| Static gobo wheel | 7 gobos plus open, wheel indexing, rotation and shake |
| Iris | 0-100% |
| Zoom | Motorized |
| Color temperature control | Variable 6500 - 2700 K |
| Prism | 2 rotating/indexing prisms (4-facet circular and 6-facet linear) |
| Frost | Soft frost effect and heavy frost effect |
| Pan | 540°, coarse & fine control and speed |
| Tilt | 260°, coarse & fine control and speed |
| Focus | Motorized |
| CONTROL AND PROGRAMMING | |
| Control options | DMX |
| 16-bit control | Dimming, CMY, CTO, pan and tilt |
| Setting and addressing | Control panel with backlit LCD display |
| DMX compliance | USITT DMX512/1990 |
| RDM compliance | ANSI/ESTA E1.20 |
| Transceiver | Opto-isolated RS-485 |
| DMX channels, ERA 800 Profile | 36 |
| OPTICS | |
| Front lens diameter | 160 mm (6.3 in.) |
| Zoom range | 7° - 56° (1:8) |
| Light source | 800 W LED engine |
| Minimum LED lifetime | 20 000 hours (to >70% luminous output)* |
| PHOTOMETRIC DATA | |
| Light engine luminous output | 70 000 lumens |
| Fixture luminous output | 34 000 lumens |
| CRI (Color Rendering Index) | >70 |
| CQS (Color Quality Scale) | >67 |
| TM-30 Rf (IES TM-30-15 Fidelity Index) | >65 |
| TM-30 Rg (IES TM-30-15 Gamut Index) | >93 |
| TLCI (Television Lighting Consistency Index) | >44 |
| CCT | 6500 K (+/- 250 K) |
| LED refresh rate | 3600 Hz |
| CONSTRUCTION | |
| Housing | High-impact flame-retardant thermoplastic |
| Color | Black |
| Protection rating | IP20 |
| GOBOS | |
| Maximum image diameter | 25 mm (0.98 in.) |
| Gobo material | Borofloat 33 |
| External diameter | 30.0 mm +0 / -0.2 mm (1.181 in. +0 / -0.008 in.) |
| Maximum gobo thickness | 1.1 mm (0.04 in.) |
| Coating | Heavy matted aluminum |
| INSTALLATION | |
| Mounting points | 2 pairs of 1/4-turn points for 106 mm (4.17 in.) center-to-center omega brackets |
| Location | Dry location only, must be fastened to surface or structure |
| Orientation | Any |
| Minimum distance to combustible materials | 0.2 m (8 in.) |
| Minimum distance to illuminated surfaces | 2.0 m (6.6 ft.) |
| CONNECTIONS | |
| DMX and RDM data in/out | 5-pin locking XLR |
| AC mains power input | Neutrik TRUE1 socket, accepts TRUE1 NAC3FX-W (TOP) connector |
| AC mains power throughput | Neutrik TRUE1 socket, accepts TRUE1 NAC3MX-W (TOP) connector |
| ELECTRICAL | |
| AC power | 100-240 VAC (nominal), 50/60 Hz |
| Power supply unit | Auto-ranging electronic switch mode |
| Half-cycle RMS inrush current at 230 V, 50 Hz | 10.3 A |
| Typical power consumption, all effects static, zero light output | 64 W |
| Maximum total power consumption | 1397 W |
| Recommended MCB (Miniature Circuit Breaker) per IEC 60898/UL489/CSA C22.2 No. 5 | Type D |
| TYPICAL POWER AND CURRENT | |
| 120 V, 60 Hz | 10.8 A, 1270 W, PF 0.99 |
| 230 V, 50 Hz | 5.5 A, 1240 W, PF 0.97 |
| THERMAL | |
| Cooling | Forced air (temperature-regulated, low noise) |
| Maximum ambient temperature (Ta max.) | 40° C (104° F) |
| Minimum ambient temperature (Ta min.) | 5° C (41° F) |
| Maximum surface temperature, steady state, at 40° C ambient | 70° C (158° F) |
| Maximum total heat dissipation, calculated, +/- 10% | 4770 BTU/hr. |
| APPROVALS | |
| EU safety | EN 60598-2-17 (EN 60598-1), EN 62471, EN62493 |
| EU EMC | EN 55015, EN 55032, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61547 |
| US safety | UL 1573 |
| US EMC | FCC Part 15 Class B |
| Canadian safety | CSA C22.2 No. 166 |
| Canadian EMC | ICES-3 (B) / NMB-3 (B); ICES-5 (B) / NMB-5 (B) |
| Australia/NZ | RCM |
| Global CB Certification/IECEE | IEC 60598-2-17 (IEC 60598-1) |
| INCLUDED ITEMS | |
| Two omega brackets with 1/4 turn fasteners for rigging clamp attachment | 2 x P/N 91602001 |
| SKU | Manufacturer’s SKU | Image | Name | Colour/description |
|---|---|---|---|---|
| MAR1834 | 9025123581 | | ERA 800 Profile | |
| MAR1835 | 9025123582 | | ERA 800 Profile White | ERA 800 Profile (White) in cardboard box: P/N 9025123582 |
