ERA 600 Performance

550W LED based profile with framing and CMY colour mixing

SRP from £6,320.00 + VAT

Designed to fulfill the demand for a bright, compact, tour-worthy moving head, the Martin ERA 600 Performancecombines a feature-loaded and rugged, yet cost-efficient profile for entertainment and rental applications. It features a highly efficient 550W white LED engine that produces a bright, sharp 6,500K image projection with a flat field.

Additional key benefits include 1:8 zoom, electronic dimming and strobe, full CMY color mixing and separate color wheel, variable color temperature control, animation wheel, iris for beam adjustment and fixed and rotating gobo wheels, loaded with user-favorite gobos from the renowned Martin MAC range that include a wide variety of effects, especially when combined with the two included rotating prisms and soft frost filter.The ERA 600 Performanceincludes a full curtain framing system which offers lighting designers a high degree of flexibility to achieve precise looks on stage.

When fully focused, gobos can be nicely framed with a soft edge, and each of the four framing blades can cross the entire beam independently for a full blackout. The entire system can rotate 120 degrees, allowing designers to direct light exactly where they want it to go and achieve unique movement effects not otherwise possible.Perfect for larger stage and live productions, the Martin ERA 600 Performanceis ideal for a long list of scenarios, requiring a bright, yet truly versatile LED profile that offers near limitless design and usage potential.

The full curtain framing system allows each of the four framing blades to cross the entire beam independently for full blackout. In addition, the entire framing module can rotate 120 degrees, allowing for precise and accurate image projection for the desired stage area. When fully focused, gobos can be framed with a soft edge, enabling designers a high degree of flexibility in the lighting design.


With an efficient 550 watt light source, the ERA 600 Performance delivers more output than similar-sized fixtures. Fully electronic dimming ensures extremely fast strobing, instant intensity control, and a flat, consistent field that can be maintained down to zero percent.

Precise color temperature control with variable color temperature correction (CTO). Vibrant CMY color mixing from light and smooth pastels to rich, saturated primaries. The color wheel produces nice color splits, fast color bumps & extends overall color gamut and brightness.

With 6 to 45 degrees of zoom, the ERA 600 Performance works great even on larger trim heights. Zooming is fast and accurate and maintains a high output throughout the range.

The ERA 600 Performance is a very compact and low weight for its class making it easy to handle and rig. The modular design makes accessing & replacing of effects safe, quick, and easy – modules can be swapped in less than a minute.

Electronic 'shutter' effectStrobe effect, pulse effects, instant open and blackout
Electronic dimming0 - 100%, four dimming curve options
Colour mixingCMY, independently variable 0-100%
Colour temperature controlVariable 6500 - 2700 K
Colour wheel7 colour filters plus open
Rotating gobo wheel7 gobos plus open, wheel rotation, gobo rotation, indexing and shake
Static gobo wheel8 gobos plus open, wheel indexing, rotation and shake
Gobo animationAnimation wheel, indexing, continuous rotation with variable speed and direction
FramingRotatable framing module, +/-60°, with 4 individually controllable full framing blades with variable angle and position
Prism2 rotating/indexing prisms (4-facet circular prism and 6-facet linear)
FrostSoft frost effect and heavy frost effect
Pan540°, coarse & fine control and speed
Tilt260°, coarse & fine control and speed
Control optionsDMX
16-bit controlDimming, pan and tilt
Setting and addressingControl panel with backlit LCD display
DMX channels41
DMX complianceUSITT DMX512/1990
RDM complianceANSI/ESTA E1.20
TransceiverOpto-isolated RS-485
Front Lens Diameter120 mm
Zoom range6° - 45° (1:8)
Light source550W LED engine
Minimum LED lifetime20000 hours (to >70% luminous output)*
Light engine luminous output37000 lumens
Fixture luminous output19000 lumens
CRI (Color Rendering Index)>70
CCT6500 Kelvin (+/- 350K)
LED refresh rate3600 Hz
HousingHigh-impact flame-retardant thermoplastic
Protection ratingIP 20
Gobo diameter23.0 mm +0/- 0.2 mm (in. +0/- 0.008 in.)
Maximum image diameter19.0 mm (0.98 in.)
Gobo thickness, maximum1.1 mm (0.04 in.)
Installation mounting pointsTwo quarter-turn brackets for rigging clamps
AC power input, thruNeutrik powerCON TRUE1
DMX data in/out5-pin locking XLR
AC power100-240V nominal, 50/60 Hz
Power supply unitAuto-ranging electronic switch mode
Steady Power Consumption85 W, all effects static, zero light output
Half-cycle RMS inrush current21.7 A (at 230 V, 50 Hz)
120V, 60Hz6.5A, 778W, PF 0.99
230V, 50Hz3.15A, 760W, PF 0.97
CoolingForced air (temperature regulated, low noise)
Maximum ambient temperature (Ta max.)40° C
Minimum ambient temperature (Ta min)0° C
Maximum surface temperature, steady state75° C (167° F) at 40° C ambient
Total heat dissipation2660 BTU/hr. (calculated, +/- 10%)
EU safetyEN 60598-2-17 (EN 60598-1), EN 62471, EN 62493
EU EMCEN 55015; EN 55032; EN 55035; EN 61000-3-2,-3; EN 61547
US safetyUL 1573
US EMC.FCC Part 15 Class B
Canadian safetyCSA C22.2 No. 166
Canadian EMCICES-003 Class B, ICES-005 Class B
Global CB Certification/IECEEIEC 60598-2-17 (IEC 60598-1)
Length416 mm (17in.)
Width290 mm (11.4in.)
Height734 mm (31.5in)
Weight30.0 kg (87.1lbs)
  • Bright 550 watt / 6,500K LED light source
  • 19,000 lumen output
  • Crisp optics with flat field
  • Fat beam look with 120 mm front lens
  • 1:8 Fast zoom
  • CMY color mixing - Vibrant color mixing with a superior palette of colors
  • Linear CTO – Daylight to tungsten CCT control and expansion of the CMY palette
  • 7-slot colour wheel –for added colour choice and split colour effects
  • Full Curtain Framing blades with +/- 60° rotation of entire system for flexible shape generation
  • 7 rotating/indexing gobos – All renowned Martin glass gobos
  • 8 static gobos for great morphing effects
  • Animation wheel with continuous bi-directional rotation
  • Two prisms - 4-facet and linear – rotation and index control for dynamic effects
  • Soft frost – A light frost leaves gobo artwork visible with a beautiful soft edge
  • Compact and low weight design
SKU Manufacturer’s SKU Image Name Colour/description
MAR1773 9025122049 Martin ERA 600 Performance Martin ERA 600 Performance Martin ERA 600 Performance in cardboard box: P/N 9025122049
MAR1809 9025122050 Martin ERA 600 Performance WHITE Martin ERA 600 Performance WHITE Martin ERA 600 Performance – White in cardboard box: P/N 9025122050
